125-1302 1251302 CAT Relay Starter SWITCH GP-MAGNETIC Relays With Harness Caterpillar 311B 312D 324D 365B 318C Excavator Spare Parts
125-1302: SWITCH GP-MAGNETIC
SWITCH GP-MAGNETIC
125-1302 SWITCH GP-MAGNETIC
S/N 2JR1-UP
24-VOLT
PART OF 134-8234 PANEL GP-CIRCUIT BREAKER
AN ATTACHMENT
1251302 SWITCH GP-MAGNETIC Parts scheme
Parts for your 325B L EXCAVATOR:
CATERPILLAR SIS
Pos. Part No Qty Parts name Comments
1. 102-8802 [1] KIT-RECEPTACLE (2-PIN)
(INCLUDES RECEPTACLE AS & WEDGE)
2. 186-3735 [2] PIN-CONNECTOR (16-GA TO 18-GA)
3. 1H-3338 [2] LOCKWASHER (EXTERNAL TOOTH)
4. 3B-4504 [2] LOCKWASHER
5. 5C-2890 M [2] NUT (M6X1-THD)
6. 9X-1813 E SLEEVE (16-CM)
E ORDER BY THE CENTIMETER
M METRIC PART
The price is for reference only, please contact us by email and the actual quotation shall prevail.
| PACKAGE: | Original packing or Neutral packing with wooden box or carton. |
| SHIPPING: | It could be shipped by sea,by air or by express(EMS,UPS,DHL,TNT,FEDEX and etc). |
| PAYMENT: | T/T,Western Union,Paypal,Alipay,Cash. |
| LADING: | When the goods shipping , i will email u for tracking number for goods. i can offer bill of lading to u . |
