YN11M01013D1 GOVERNOR Throttle MOTOR CONTROL LEVER Kobelco

YN11M01013D1 2420T8896 HR37C08000G1 GOVERNOR Throttle MOTOR BALL JOINT FLEXIBLE CONTROL LEVER Kobelco Excavator Parts

Product Description

• Part Number:  YN11M01013D1 2420T8896 HR37C08000G1

• Description: GOVERNOR Throttle MOTOR CONTROL LEVER Kobelco

• Engine Brand: ISUZU/HINO/MISTUBISHI/YANMAR

• Excavator Brand: New Holland KOBELCO/HITACHI/CAT/KOMATSU

• Place of Origin:China/Japan

• Packing: Original packing or Neutral packing

YN11M01013D1 2420T8896 HR37C08000G1 GOVERNOR Throttle MOTOR BALL JOINT FLEXIBLE CONTROL LEVER Kobelco Excavator Parts

41 1 2406R1161 ROD
39 3 ZW26K10000 WASHER Lock -- ID 10 x OD 15.7 x Th 2.5mm
38 3 2420N458D10025 SCREW
37 2 ZW16X06000 WASHER ID 06 x OD 12.5 x Th 1.6mm
36 3 ZN18C05004 NUT M05x0.8mm
35 2 2420Z1320D3 ROD
34 1 LQ11M01008P1 FLEXIBLE CONTROL
33 1 2406R522D2 CABLE
32 1 2418T28483 PLATE
31 1 2416N7688 BRACKET YCU0603-UP
30 1 2432T4615 LABEL Decal -- 45x45mm Red triangle
29 1 ZN18C08007 NUT M08x1.25mm
28 1 ZW26X12000 LOCK WASHER ID 12 x OD 21 x Th 3.0mm
27 1 ZW16X12000 WASHER ID 12 x OD 24 x Th 2.3mm
26 1 ZS18C12025 SCREW M12x1.75x25mm
25 1 2420T7359 NUT M08x1.25mm -- Left Hand Threads
23 1 2420T7840 NUT M08x1.0mm
22 1 ZN18F08007 NUT M08x1.0mm
21 1 ZN18C06005 NUT M06x1.0mm
20 3 ZW16X10000 WASHER ID 10 x OD 21 x Th 2.0mm
19 1 ZW22K06000 LOCK WASHER ID 06 x OD 10 x Th 1.5mm
18 6 ZW26X10000 LOCK WASHER ID 10 x OD 18 x Th 2.5mm
17 1 ZW26X08000 WASHER Lock -- ID 08 x OD 15 x Th 2.0mm
16 2 ZW26X06000 LOCK WASHER ID 06 x OD 07 x Th 1.5mm
15 1 2420N458D06025 SCREW
14 3 ZS18C10080 SCREW M10x1.50x80mm
13 3 ZS18C10025 SCREW M10x1.50x25mm
12 2 ZS18C08014 SCREW M08x1.25x14mm
11 2 ZS18C06016 SCREW M06x1.0x16mm
10 2 2419R9D1 COTTER PIN OD 06mm x 21.2mm Long
9 1 2419Z216 PIN
8 1 2418T27216 PLATE
7 1 2406T3075 LEVER
6 1 2420Z2229 ROD
5 1 2420Z2228 ROD
3 1 2420Z1422 STUD
2 1 2406U197F4 SMALL ELECTRIC MOTOR
1 1 2416P20783 BRACKET
24 1 YN11M01013D1 BALL JOINT M08x1.25x36mm Long
33 2 ZM61C06016 BOLT M06x1.0x16mm (Incls. Washer & Lockwasher)
32 1 2432R233D3 CLIP 50x16x60mm
31 1 2432T4615 LABEL Decal -- 45x45mm Red triangle
30 1 2420Z1330 GROMMET
29 1 ZN18C06005 NUT M06x1.0mm
28 1 YN11M01093P1 PIN
27 2 ZS18C08030 SCREW M08x1.25x30mm
26 4 ZW26X08000 WASHER Lock -- ID 08 x OD 15 x Th 2.0mm
25 2 2420T4505 WASHER ID 07 x OD 16 x Th 1.0mm
24 1 YN11M01102P1 PLATE
23 1 YN11M01075P1 FLEXIBLE CONTROL
22 3 ZS28C10035 CAP Screw -- M10x1.50x35mm
21 2 YN11M01079P1 BOSS
20 3 ZS18C10020 SCREW M10x1.50x20mm
19 1 YN11M01095P1 FLEXIBLE CONTROL
18 1 YN11M01114P2 PIN Was YN11M01114P1
17 1 2420T7359 NUT M08x1.25mm -- Left Hand Threads
16 2 2419R9D1 COTTER PIN OD 06mm x 21.2mm Long
14 2 ZS18C06060 SCREW M06x1.0x60mm
13 3 ZW26X06000 LOCK WASHER ID 06 x OD 07 x Th 1.5mm
12 1 ZS28C06025 SCREW M06x1.0x25mm
11 1 ZW16X06000 WASHER ID 06 x OD 12.5 x Th 1.6mm
10 1 LQ11M01055P1 U-BRACKET
9 3 ZW26X10000 LOCK WASHER ID 10 x OD 18 x Th 2.5mm
8 4 ZM22C10025 BOLT M10x1.50x25mm (Incls. Washer & Lockwasher)
7 3 ZN18C08007 NUT M08x1.25mm
6 1 HR37C08000G1 BALL JOINT Replaces 2425R227D2, M08x1.25x45.5mm Long
5 1 2420T8896 ROD
4 1 YT20S00002F2 HYD CONNECTOR
3 1 YN11M01091P1 LEVER
2 1 YN11M01113P1 LEVER
1 1 YN11M01111P2 BRACKET Was YN11M01111P1
YN11M00007F1 CONTROL ASSY,ENGINE
15 1 YN11M01013D1 BALL JOINT M08x1.25x36mm Long
