20 1 VAME219070 HOSE HOSE
19 1 VAME084614 VALVE BY-PASS VALVE
17 1 VAME014499 GASKET THERMOSTAT KIT
16 1 VAME049303 STARTER MOTOR STARTER ASSY
15 1 VAME088887 ALTERNATOR ALTERNATOR ASSY
14 1 VAME088532 FILTER FILTER ELEMENT,OIL
13 1 VAME015254 ELEMENT FILTER ELEMENT,FUEL
12 1 VAME088841 GASKET GASKET
11 1 VAMC867765 SENSOR LEVEL SENSOR,OIL
10 1 VAMC849577 SENSOR SENSOR,SPEED
g 1 VAMC840219 SWITCH PRESS SWITCH,OIL
8 2 VAMH014090 BELT V-BELT
7 1 VAME072890 HEATER GLOW RELAY
6 1 VAME077148 RELAY SAFETY RELAY (INP)
MITSUBISHI PARTS NO. As for the engine parts,refer to following "Engine parts"
5 1 YN20M01282D1 V-BELT 48.82" L, (Air Conditioner), (COG B47.5)
4 1 YN05P01045P1 HOSE HOSE,RADIATOR
3 1 YN05P01046P1 HOSE
2 1 YT52S00001P1 SENSOR Coolant Temperature (Thermo)
1 1 YN02P00010F1 ENGINE ENGINE
18 1 VAME039860 SWITCH SWITCH,THERMO
21 1 VAME995300 THERMOSTAT KIT, Remarks: 76.5DEGREE C
20 1 VAME077796 STARTER MOTOR (24V-5.0KW)
VAME049321C CORE-ALTERNATOR Return Number, N.A. Only
1 VAME049321R REMAN-ALTERNATOR For N.A. Only
19 1 VAME049321 ALTERNATOR (24V-35A)
18 1 VAME072937 SWITCH OIL FILTER BY-PASS
17 1 VAME130968 ELEMENT OIL (SPIN-ON)
16 1 VAME056670 ELEMENT FUEL SPIN-ON)
15 1 VAME034997 SEAL RETAINER
14 1 VAME034998 PISTON RING SET
13 1 VAMC867765 SENSOR OIL LEVEL (SW-23)
12 1 VAMC849577 SENSOR SPEED (SE-13)
11 1 VAMC840219 SWITCH OIL PRESSURE (SW-7)
10 2 VAMH014493 SET OF 2 BELTS V-BELT - 1130mm Long (44-31/64 in)
9 1 VAME049308 RELAY GLOW RELAY (R-3)
8 1 VAME075970 RELAY STARTER RELAY (R-2)
7 1 VAME049239 RELAY SAFETY RELAY (R-4)
MITSUBISHI COMPONENTS
6 1 YN20M01282D2 BELT, TRANSMISSION V-BELT (A/C)
5 1 LB05P01048P1 FLEXIBLE HOSE
4 1 LB05P01065P1 RADIATOR HOSE
3 1 LB05P01066P1 RADIATOR HOSE
2 1 YT52S00001P1 SENSOR Coolant Temperature (Thermo)(SE-14)
1 1 LB02P00007F1 ENGINE (6D16-TLEG)
ENGINE ASSY
22 1 VAME039860 SWITCH THERMO (SW-6), Remarks: 105.5DEGREE C
The price is for reference only, please contact us by email and the actual quotation shall prevail.
| PACKAGE: | Original packing or Neutral packing with wooden box or carton. |
| SHIPPING: | It could be shipped by sea,by air or by express(EMS,UPS,DHL,TNT,FEDEX and etc). |
| PAYMENT: | T/T,Western Union,Paypal,Alipay,Cash. |
| LADING: | When the goods shipping , i will email u for tracking number for goods. i can offer bill of lading to u . |
| Main System | Subsystems |
|---|---|
| 1. Power System |
- Engine - Air Intake System - Fuel Supply System - Lubrication System - Cooling System - Exhaust System |
| 2. Hydraulic System |
- Main Pump - Control Valve - Main Control Valve - Hydraulic Cylinders (Boom, Arm, Bucket) - Swing Motor - Travel Motor - Relief / Safety Valve - Hydraulic Tank & Filters - Pilot Control System |
| 3. Electrical System |
- ECU & Monitor - Battery - Starter & Alternator - Wiring Harness - Sensors (Pressure, Temp, Position) - Solenoid Valves - Lighting & Alarm System |
| 4. Working Equipment |
- Boom - Arm / Stick - Bucket - Quick Coupler - Attachments (Breaker, Grapple, Shear) |
| 5. Undercarriage / Travel System |
- Tracks / Tires - Track Rollers, Carrier Rollers, Idlers - Track Tensioner - Travel Motor & Reducer |
| 6. Swing System |
- Swing Motor - Swing Reducer - Swing Bearing - Swing Brake |
| 7. Control System |
- Operator Cab - Joysticks - Pedals & Levers - A/C System - Camera & Monitor System |
| 8. Lubrication & Maintenance |
- Hydraulic Oil Filter - Fuel Filter - Air Filter - Grease Points - Auto Greasing System (optional) |
