021. 8971019740 [1] COVER; HOLE
244. 0280506160 [1] BOLT; COVER M6X16 FLANGE
273. 8973679841 [3] CLIP; HARNESS ID=12
389. 9095714160 [1] GASKET; SWITCH ID=16.2 OD=24<BR>ALSO INCLUDED IN GASKET SET(ENGINE)
420(A). 0920024160 [1] PLUG; SWITCH M16X12
448(A). 0280506120 [1] BOLT; SENSOR M6X12 FLANGE
448(B). 0280508200 [2] BOLT; SENSOR M8X20 FLANGE
465. 0280506160 [3] BOLT; CLIP M6X16 FLANGE
553. 8973694040 [1] GASKET
598. 0015583000 [2] HOSE; RUBBER,SENSOR L=210 SB=3000
599. 8973296270 [4] CLIP; HOSE ID=13
635. 8976069430 [1] SENSOR; TACHOMETER
701(A). 8980316051 [1] SENSOR; DPD FRONT
701(A). 8981783581 [1] SENSOR; DPD FRONT
701(B). 8973672655 [1] SENSOR; DPD CENTER
701(B). 8981867621 [1] SENSOR; DPD CENTER
747. 8981331241 [1] CONTROL UNIT; TURBOCHARGER
775. 8973603682 [1] SENSOR; PRESS
The price is for reference only, please contact us by email and the actual quotation shall prevail.
| PACKAGE: | Original packing or Neutral packing with wooden box or carton. |
| SHIPPING: | It could be shipped by sea,by air or by express(EMS,UPS,DHL,TNT,FEDEX and etc). |
| PAYMENT: | T/T,Western Union,Paypal,Alipay,Cash. |
| LADING: | When the goods shipping , i will email u for tracking number for goods. i can offer bill of lading to u . |
| Main System | Subsystems |
|---|---|
| 1. Power System |
- Engine - Air Intake System - Fuel Supply System - Lubrication System - Cooling System - Exhaust System |
| 2. Hydraulic System |
- Main Pump - Control Valve - Main Control Valve - Hydraulic Cylinders (Boom, Arm, Bucket) - Swing Motor - Travel Motor - Relief / Safety Valve - Hydraulic Tank & Filters - Pilot Control System |
| 3. Electrical System |
- ECU & Monitor - Battery - Starter & Alternator - Wiring Harness - Sensors (Pressure, Temp, Position) - Solenoid Valves - Lighting & Alarm System |
| 4. Working Equipment |
- Boom - Arm / Stick - Bucket - Quick Coupler - Attachments (Breaker, Grapple, Shear) |
| 5. Undercarriage / Travel System |
- Tracks / Tires - Track Rollers, Carrier Rollers, Idlers - Track Tensioner - Travel Motor & Reducer |
| 6. Swing System |
- Swing Motor - Swing Reducer - Swing Bearing - Swing Brake |
| 7. Control System |
- Operator Cab - Joysticks - Pedals & Levers - A/C System - Camera & Monitor System |
| 8. Lubrication & Maintenance |
- Hydraulic Oil Filter - Fuel Filter - Air Filter - Grease Points - Auto Greasing System (optional) |
