01. J011025 [2] BOLT;SEMS
03. 4332040 [1] SENSOR;PRES. (ARM ROLL-IN)
03A. 957366 [1] O-RING
04. 4333040 [1] SWITCH (BOOM RAISE)
04A. 957366 [1] O-RING
07. 4367131 [1] VALVE;FC
01. 4156434 [2] ELBOW;S
01A. 957366 [1] O-RING
02. 4200467 [2] ADAPTER;S
02A. 957366 [1] O-RING
04. 4246672 [2] UNION;M
06. 9161967 [1] HOSE ASS'Y
06A. 4368703 [1] HOSE (P)
06B. 4327293 [1] PROTECTOR
07. 9161968 [1] HOSE ASS'Y
07A. 4368704 [1] HOSE (T)
07B. 4327293 [1] PROTECTOR
10. 9746294 [1] BRACKET
11. J011030 [2] BOLT;SEMS
12. 4330230 [1] VALVE;SHUTTLE
13. J010816 [2] BOLT;SEMS
15. 4200466 [4] ADAPTER;S
15A. 4509180 [1] O-RING
18. 4364795 [1] HOSE (2)
19. 4372796 [1] HOSE (1)
26. 4372960 [1] HOSE (1)
27. 4372986 [1] HOSE (2)
28. 4332040 [1] SENSOR;PRES.
28A. 957366 [1] O-RING
29. 4365080 [1] HARNESS;WIRE
31. 4093624 [1] PLUG
31A. 957366 [1] O-RING
33. 4190282 [2] CLIP
34. 4055312 [5] CLIP;BAND
The price is for reference only, please contact us by email and the actual quotation shall prevail.
| PACKAGE: | Original packing or Neutral packing with wooden box or carton. |
| SHIPPING: | It could be shipped by sea,by air or by express(EMS,UPS,DHL,TNT,FEDEX and etc). |
| PAYMENT: | T/T,Western Union,Paypal,Alipay,Cash. |
| LADING: | When the goods shipping , i will email u for tracking number for goods. i can offer bill of lading to u . |
| Main System | Subsystems |
|---|---|
| 1. Power System |
- Engine - Air Intake System - Fuel Supply System - Lubrication System - Cooling System - Exhaust System |
| 2. Hydraulic System |
- Main Pump - Control Valve - Main Control Valve - Hydraulic Cylinders (Boom, Arm, Bucket) - Swing Motor - Travel Motor - Relief / Safety Valve - Hydraulic Tank & Filters - Pilot Control System |
| 3. Electrical System |
- ECU & Monitor - Battery - Starter & Alternator - Wiring Harness - Sensors (Pressure, Temp, Position) - Solenoid Valves - Lighting & Alarm System |
| 4. Working Equipment |
- Boom - Arm / Stick - Bucket - Quick Coupler - Attachments (Breaker, Grapple, Shear) |
| 5. Undercarriage / Travel System |
- Tracks / Tires - Track Rollers, Carrier Rollers, Idlers - Track Tensioner - Travel Motor & Reducer |
| 6. Swing System |
- Swing Motor - Swing Reducer - Swing Bearing - Swing Brake |
| 7. Control System |
- Operator Cab - Joysticks - Pedals & Levers - A/C System - Camera & Monitor System |
| 8. Lubrication & Maintenance |
- Hydraulic Oil Filter - Fuel Filter - Air Filter - Grease Points - Auto Greasing System (optional) |
