EXCAVATOR 311B 312B 315B 318B 320B 325B 330B Caterpillar Excavator Air Conditioner Compressor A/C Condenser Evaporator Blower Air conditioning expansion valve Air Conditioning Ducts Control panel Servo motor
154-0490 1540490 COMPRESSOR Motor Assembly Air Conditioner AC Caterpillar CAT 311B 312B 315B 318B 320B 325B 330B Excavator Parts
154-0490 1540490 COMPRESSOR Motor Assembly Air Conditioner AC Caterpillar CAT 311B 312B 315B 318B 320B 325B 330B Excavator Parts
159-7855 AIR CONDITIONER GP
COMPRESSOR GP-REFRIGERANT
109-9506 COMPRESSOR GP-REFRIGERANT
COMPRESSOR GP-REFRIGERANT
154-0445 COMPRESSOR GP-REFRIGERANT
COMPRESSOR GP-REFRIGERANT
3E-1906 COMPRESSOR GP-REFRIGERANT
CONDENSER & MTG GP-REFRIGERANT
117-6317 CONDENSER & MTG GP-REFRIGERANT
CONDENSER & MTG GP-REFRIGERANT
154-0440 CONDENSER & MTG GP-REFRIGERANT
#SEBP27810360
154-0445: COMPRESSOR GP-REFRIGERANT
COMPRESSOR GP-REFRIGERANT
154-0445 COMPRESSOR GP-REFRIGERANT
S/N 4XW1-UP; 5GW221-UP
PART OF 155-7080 INSTALLATION AR-ENGINE
1540445 COMPRESSOR GP-REFRIGERANT Parts scheme
For full view, you need register
Parts for your 320B EXCAVATOR:
CATERPILLAR SIS
Pos. Part No Qty Parts name Comments
1. 8T-4121 [7] WASHER-HARD (11X21X2.5-MM THK)
2. 8T-4182 M [4] BOLT (M10X1.5X45-MM)
3. 8L-8646 [1] V-BELT
4. 8T-4172 M [3] BOLT (M10X1.5X80-MM)
5. 154-0490 [1] COMPRESSOR GP-REFRIGERANT
6. 154-0446 [1] BRACKET AS
7. 118-9863 [1] PULLEY
8. 8T-4223 [2] WASHER-HARD (13.5X25.5X3-MM THK)
9. 8T-4184 M [2] BOLT (M12X1.75X45-MM)
10. 085-7329 [4] SPACER (9X19X30-MM THK)
11. 7X-2540 M [4] BOLT (M8X1.25X120-MM)
12. 8T-4224 [4] WASHER-HARD (8.8X16X2-MM THK)
13. 154-0491 [1] PULLEY GP-IDLER
M METRIC PART
#SEBP27810361
3E-1906: COMPRESSOR GP-REFRIGERANT
COMPRESSOR GP-REFRIGERANT
3E-1906 COMPRESSOR GP-REFRIGERANT
S/N 4XW1-UP; 5GW1-UP
PART OF 109-9506 COMPRESSOR GP-REFRIGERANT
3E1906 COMPRESSOR GP-REFRIGERANT Parts scheme
Parts for your 320B EXCAVATOR:
CATERPILLAR SIS
Pos. Part No Qty Parts name Comments
1. 9X-3401 [2] PIN-CONNECTOR (16-GA TO 18-GA)
2. 102-8802 [1] KIT-RECEPTACLE (2-PIN)
(INCLUDES RECEPTACLE AS & WEDGE)
3. 314-4018 [1] VALVE AS-PRESSURE RELIEF (REFRIGERANT COMPRESSOR)
9X-7378 [1] SEAL-O-RING
4. 7T-4532 [1] PLUG AS
5. 9X-7385 [2] SEAL-O-RING
#SEBP27810362
117-6317: CONDENSER & MTG GP-REFRIGERANT
CONDENSER & MTG GP-REFRIGERANT
117-6317 CONDENSER & MTG GP-REFRIGERANT
S/N 4XW1-UP; 5GW1-UP
PART OF 109-9502 INSTALLATION AR-ENGINE
1176317 CONDENSER & MTG GP-REFRIGERANT Parts scheme
Parts for your 320B EXCAVATOR:
CATERPILLAR SIS
Pos. Part No Qty Parts name Comments
1. [1] BRACKET AS
6V-9632 M [4] NUT-WELD (M6X1-THD)
2. 7X-2534 M [8] BOLT (M6X1X50-MM)
3. 095-0827 [8] LOCKWASHER
4. 9X-8256 [8] WASHER (6.6X12X2-MM THK)
5. 8T-4137 M [4] BOLT (M10X1.5X20-MM)
6. 8T-4121 [4] WASHER-HARD (11X21X2.5-MM THK)
7. [1] BRACKET AS
6V-9632 M [4] NUT-WELD (M6X1-THD)
8. 105-9407 [1] CONDENSER AS
M METRIC PART
#SEBP27810363
154-0440: CONDENSER & MTG GP-REFRIGERANT
CONDENSER & MTG GP-REFRIGERANT
154-0440 CONDENSER & MTG GP-REFRIGERANT
S/N 4XW104-UP; 5GW221-UP
PART OF 155-7080 INSTALLATION AR-ENGINE
1540440 CONDENSER & MTG GP-REFRIGERANT Parts scheme
Parts for your 320B EXCAVATOR:
CATERPILLAR SIS
Pos. Part No Qty Parts name Comments
1. 8T-4137 M [4] BOLT (M10X1.5X20-MM)
2. 8T-4121 [4] WASHER-HARD (11X21X2.5-MM THK)
3. 159-7751 [1] BRACKET AS
8T-3490 M [1] NUT-WELD (M10X1.5-THD)
8T-3612 M [2] NUT-WELD (M8X1.25-THD)
4. 159-7749 [1] BRACKET AS
8T-3612 M [2] NUT-WELD (M8X1.25-THD)
5. 130-0253 [1] CONDENSER AS
6. 8T-4200 M [4] BOLT (M8X1.25X16-MM)
7. 8T-4224 [4] WASHER-HARD (8.8X16X2-MM THK)
M METRIC PART
